Hi DIYers! Today, we are happy to unveil the Honeywell Home VISTA-21iPLTE. This is the newest hardwired system from the VISTA Series by Resideo, and it is essentially replacing the existing VISTA-21iP System. The big addition is its ability to support special plug-in LTE communicators.



The Honeywell Home VISTA-21iPLTE is actually the same as a VISTA-21iP System, except that the 21iPLTE board has been upgraded to support new plug-in LTE communicators. This includes the Honeywell Home LTE-21V with Verizon LTE (available now) and the Honeywell Home LTE-21A (coming soon).

These new plug-in modules are just like the older Honeywell VISTA-GSM4G Communicator, which conveniently plugged into the VISTA-21iP board. The only difference is that the LTE-21V and LTE-21A support LTE connectivity. This is important for anyone looking to use cellular communication with a security system.

The reason you want to use an LTE communicator with your alarm system is because it offers superior speed and reliability when compared with older 3G and CDMA networks. Also, these older networks are in the process of being shutdown. By going with LTE, you are providing a long-term solution for your panel.

Just like the existing VISTA-21iP, the new VISTA-21iPLTE has a built-in IP communicator, which is basically the equivalent of a Honeywell 7847i Communicator. Even if you don't add a cell module to the VISTA-21iPLTE, you will still be able to connect it with AlarmNet for IP monitoring and access to Total Connect 2.0.

Honeywell vista gsm4g alarmnet vista 21ip cellular alarm monitor

But adding a cellular communicator is very important for dealing with internet outages. If the internet goes out and you don't have a cellular backup, then your 21iPLTE will lose connectivity with the AlarmNet360 Servers. Maintaining this connection is required for monitoring service. This makes cellular backup crucial!

By connecting your VISTA-21iPLTE Panel with AlarmNet360, you will also be able to control your system through Total Connect 2.0.This is an interactive monitoring and automation platform that you can access from nearly anywhere using your phone. Make sure you choose a monitoring plan with TC2 service!

If you plan to use cellular communication with your VISTA-21iPLTE and Alarm Grid, then you will need a Gold or Platinum Level Plan (Self or Full). This is needed to activate the cellular radio and connect it with AlarmNet360. You can find more information about all our monitoring plans on our monitoring page.

Once you have access to Total Connect 2.0, you will be able to control your 21iPLTE System from pretty much any location. You can access Total Connect 2.0 to arm and disarm, check current system status, control Z-Wave devices (controller required), view IP cameras (video monitoring required), and so much more!

Honeywell vista 21ip internet alarm control panel open

As far as functionality is concerned, the VISTA-21iPLTE is basically just like like a VISTA-21iP. Other than the added support for the LTE-21V and LTE-21A on the 21iPLTE, they are really the exact same panel. As a result, almost any specification that applies to the VISTA-21iP also applies to the VISTA-21iPLTE.

The VISTA-21iPLTE is capable of supporting up to 64 total zones. However, you can only use eight (8) hardwired zones out of the box. To use additional wired zones, you will need to add Honeywell 4219 Expansion Modules. And to use wireless sensors, you will need a wireless receiver, such as the 6160RF Keypad.

By adding up to five (5) 4219 Expansion Modules, you can use up to 48 hardwired zones on the VISTA-21iPLTE. Keep in mind that Zones 2 thru 8 support zone doubling. Zone 1 is a special zone for use with 2-wire smokes. That is why it does not support zone doubling. You can have up to 16 2-wire smokes on the zone.

Adding a compatible wireless receiver will let you use wireless 345 MHz sensors from the Honeywell 5800 Series. A standard wireless receiver will only support uni-directional (one-way) devices. But a wireless transceiver like the 6160RF will also let you use bi-directional devices. Up to 56 wireless zones can be used.

It is important to keep in mind that the total number of zones (wired and wireless) can never exceed 64. Additionally, zones 49 thru 64 on a VISTA-21iPLTE are designated as key fob zones for key fob inputs. But you can actually use these zones with any wireless sensor, as long as you have a wireless receiver added.

Honeywell 6160rf alphanumeric alarm keypad with integrated transceiver

There are also some other accessories you can add to a VISTA-21iPLTE System. First and foremost, you will want a keypad for controlling the system. As stated earlier, the Honeywell 6160RF is a great option. If you don't plan to use wireless sensors, then the standard Honeywell 6160 will work just as well.

You might also consider getting a touchscreen keypad for the system. These can be easier to use than push-button keypads. But just remember that only push-button keypads can backdoor into programming. The new Honeywell 6290W is a great option. Or you could go with the Tuxedo Touch to add Z-Wave functionality.

There are limits to the number of keypads you can use with the system. Up to eight (8) push-button keypads can be added. Touchscreen keypads count as AUI devices, and the VISTA-21iPLTE will only support a max of four (4) AUI devices. Keep in mind that the Total Connect 2.0 service also counts as an AUI device!

Speaking of Z-Wave, a Z-Wave controller is needed if you want to use Z-Wave devices with the system. Adding a Tuxedo Touch is a great way to add Z-Wave capabilities. If you already have a keypad, then the standalone Honeywell VAM is also an option. Remember, you can control all Z-Wave devices through TC2.

Ultratech 1240 alarm control panel battery backup 12v 4 dot 5ah

Lastly, the system comes with its own transformer for supplying power. You will still need to supply a backup battery like the UltraTech 1240. Power cabling is not included with the VISTA-21iPLTE system, so you must add your own. We recommend using 18-gauge wiring, or even better, a Honeywell LT-Cable.

We would also like to mention that the VISTA-21iPLTE supports two (2) partitions, along with a third common partition. It also supports other miscellaneous features like Quick Arming, Scheduling, up to 48 unique user codes, 100 event log, two (2) low-current trigger outputs, chime functionality, and more.

The VISTA-21iPLTE System and the LTE-21V LTE Communicator are both available for purchase now from the Alarm Grid website. This system is great for anyone looking for a simple, yet effective hardwired panel. It will certainly serve as a long-lasting addition to your home or business and help keep you safe.

If you have any questions about the system, please email us at support@alarmgrid.com. We will check your email at our earliest convenience and reply back as soon as we can. You may also call us at (888) 818-7728. Remember that our support hours are 9am to 8pm EST M-F. We look forward to hearing from you!

Tags: , , , , , , , , ,

Comments


Posted By

Honeywell's Total Connect 2.0 service is the best upgrade to your security system that you can make. With Total Connect 2.0 you can arm and disarm your system with the touch of a button from any computer or smartphone app. You can also have the system send you instant emails and text messages whenever a new security system event occurs. You can get a text message with the actual zone description of the device that went into alarm, the actual name of the user that armed or disarmed, even a message when your teenagers opened the liquor cabinet in the middle of the night. Once you try Total Connect 2.0 you will never look at your security system the same way again.

Of course, don't just take our word for it, try it out yourself. We now have a Total Connect Instructional demo that you can use to explore all of the exciting features of Total Connect 2.0. Even if you have already signed up for Total Connect, this demo can show you some features that you may not even know existed.

Once you have gone through the demo, go one step further and actually log into a live Total Connect 2.0 account at www.totalconnect2.com. Use 'alarmgrid' for the username and 'P@ssw0rd' for the password.

Don't forget that none of our alarm monitoring plans require a contract so if you are still on the fence about whether or not Total Connect 2.0 would work for you, try it risk free today! We even have a standalone Total Connect plan for people that don't want central station monitoring but would like the interactive features that Total Connect provides. If you decide it's not worth the cost, simply let us know and we would be happy to stop your plan.

Call us today to find out how easy it is to get fully connected to your security system with Total Connect 2.0!

UPDATE: The information from this post is now outdated. For information on how you can test drive Total Connect 2.0 now, please check this more recent post.

Tags: , , , , , , , , , , , , ,

Comments


Posted By

We have already talked about the phase out of AT&T's 2G cellular network, but if you haven't read our previous article about the new GSMX4G and GSMV4G cellular alarm communicators, then you may not know that all existing AlarmNet cellular alarm communicators will become obsolete by the end of 2016.

Here at Alarm Grid, we urge everyone looking for a new cellular alarm communicator to only invest in 4G capable communicators. AT&T has formally announced that they will have completely dropped support of the 2G cellular network by the end of 2016. As cellular data use increases, AT&T has to find ways to add new throughput to their most advanced networks. One easy way to expand that throughput is to cannibalize their older and slower 2G network. As it is extremely rare to find a cellular phone in use today that still uses the 2G network, AT&T has no problems sacrificing the older 2G network to make the newer 4G network bigger and faster. Unfortunately, the alarm industry will be affected by the discontinuation of the 2G network as nearly all cellular alarm communicators in existence today use the 2G network. Since the difference in speed between the 2G and the 3G or 4G network wasn't needed when transmitting alarm signals, cellular alarm manufacturers never bothered to upgrade their communicators to support the faster networks. Now however, all alarm companies must act and act quickly. While the end of 2016 is the formal end of the 2G cellular network, certain areas of the country will lost 2G support well before 2016.

For most people, upgrading to the newer cellular network will be as simple as swapping their existing communicator to a newer communicator that has 3G and 4G support. Unfortunately, for everyone that invested in Honeywell's VISTA-21iP alarm control panel, the change to 4G cellular alarm communications won't be so easy. The VISTA-21iP is a great security system because it has a built-in internet alarm communicator.

While internet alarm monitoring is fast and inexpensive, it is not as reliable or secure as cellular alarm communications. Therefore, the VISTA-GSM was available as a snap-on module to the VISTA-21iP to provide an integrated back up cellular communication path. For some reason, Honeywell's engineers did not design the new VISTA-GSM4G to be backwards compatible with existing VISTA-21iP security systems. Therefore, all people that have dual path alarm monitoring using a VISTA-21iP and the VISTA-GSM cellular communicator will have to replace both their VISTA-GSM communicator AND their VISTA-21iP alarm control panel if they want a system that is supported by the 3G/4G cellular network.


We are fully aware of the burden this will place on people looking to upgrade to the future of cellular communications and we will do everything we can to help those people that are left having to replace their system and their communicator. If you have a VISTA-21iP and you are wondering if it is compatible with the VISTA-GSM4G cellular add on, you will have to look at your VISTA-21iP circuit board. If there is a sticker that says "SUPPORTS VISTA-GSM/4G" then it is compatible. Without that sticker, your system will not accept a new VISTA-GSM4G. We are not sure of the exact date that Honeywell began manufacturing the new VISTA-21iP panels, and the model and revision number are the same, but we do know that it was sometime in November. Chances are, unless you got your VISTA-21iP from a reputable source in the past month or so, your system will not support the 4G cellular communicator.

Of course, here at Alarm Grid, we only ship brand new VISTA-21iP panels that have the sticker and do support the VISTA-GSM4G. If you have questions about upgrading your VISTA-21iP, please call us today.

Tags: , , , , , , , , ,

Comments


Posted By

While wireless security systems like the L5100PK LYNX Touch are easier to install then traditional wired security systems, there are some applications where the LYNX Series control panels will not be the right fit. When you have an older existing wired security system and you want to upgrade it to take advantage of today's  technology, the VISTA-21iP-6160KT is a great choice.

The VISTA-21iP-6160KT includes a VISTA-21iP alarm control panel and a 6160 alphanumeric alarm keypad. You can use the VISTA-21iP control panel to replace any existing wired security system and the 6160 will provide a keypad that you can use to program and control the VISTA-21iP. If you need additional alarm keypads because your existing wired system has more than one keypad, you can add any of the Honeywell wired alarm keypads. Every Honeywell security system needs at least one alphanumeric alarm keypad to access the more advanced programming menus. The 6160 that is included with the VISTA-21iP-6160KT will provide you with ability to program the system but you can use regular fixed English alarm keypads like the 6150 for places in your home that you'd want regular system control.

The VISTA-21iP is different than most wired alarm control panels, because it has a built-in AlarmNet internet alarm monitoring communicator that you can use to get central station monitoring. The VISTA-21iP is also compatible with AlarmNet's Total Connect interactive service. By signing up for an alarm monitoring plan that includes Total Connect, you will be able to remotely arm and disarm your VISTA-21iP from any computer or iPhone®, iPad®, Android™ or Blackberry® device. You can also setup the VISTA-21iP to send you instant emails and/or text message notifications when different security system events occur.

You can save over $100 by designing your new wired security system around the VISTA-21iP-6160KT instead of ordering the VISTA-21iP alarm control panel and the 6160 alarm keypads separately. Call us at 888-818-7728 to speak with a security expert who can advise you on which security products to add to your VISTA-21iP-6160KT so that you can get the perfect security system for your property.

Tags: , , , , , , ,

Comments


Posted By

The Honeywell L5100PK-WIFI-4G is the perfect choice for anyone that wants the most secure and reliable alarm monitoring communications available. In the past, Honeywell did not have an option for dual path alarm monitoring using the wireless all-in-one LYNX Series alarm control panels. There was no dual path alarm communicator compatible with the LYNX Series alarm control panels and you could not install both an internet alarm communicator and cellular alarm communicator inside a single LYNX system. Therefore, you had to choose between the faster, less expensive internet communications and the more reliable cellular communications. This was a disadvantage of the easier to install LYNX Series wireless alarm control panels and forced people over to the VISTA Series alarm control panels which were compatible with the discontinued 7845-iGSM and the iGSMV dual path alarm communicators.

Now however, with the Honeywell L5100 LYNX Touch system, you can use the L5100-WIFI internet communicator in conjunction with the GSMVLP5-4G cellular communicator for a true dual path alarm monitoring option using a LYNX Series wireless alarm control panel. If the internet connection ever goes down (due to a power outage or service interruption), the system will switch over to the GSMVLP5-4G and your alarm signals will go out over the AT&T cellular network.

The L5100PK-WIFI-4G includes the same (3) 5816 wireless door and window contacts, 5800PIR-RES wireless motion detector and 5834-4 wireless key fob that are included in the L5100PK LYNX Touch security system kit, but it also comes with the L5100-WIFI and GSMVLP5-4G AlarmNet communicators so you can get the peace of mind that only dual path alarm monitoring can provide.
